BreakTorq DBW1000

Price: €2.450 – €2.848

Maximum deviation +/- 1%
Breaking repeatability +/- 4%
Record “as found” results
Capture set torque for full traceability
Breaking angle of 20°
Battery life: 180 hrs
Languages: English, German, French, Spanish, Italian, Russian, Polish, Portuguese, Chinese
Units: Nm, ozf.in, lbf.in, lbf.ft, kgf.cm, kgf.m

Smart & Easy

Packed with intelligent features. Easy to master. Easy to master.

Light & Durable

Suitable for rugged conditions. Ergonomically designed for industrial use.

Familiar & Advanced

The familiar feel and efficiency of a breaking wrench with the traceability of a digital wrench.

Traceable

Transfer data via USB to PC software or upgrade to one of the wireless options.

Options

{“lang-nl”: “Model”, “lang-en”: “Model”}	{“lang-nl”: “Digitaal”, “lang-en”: “Digital”}	{“lang-nl”: “Momentbereik”, “lang-en”: “Range”}	{“lang-nl”: “Ratelkop”, “lang-en”: “Ratchet”}	{“lang-nl”: “Lengte”, “lang-en”: “Length”}	{“lang-nl”: “Gewicht”, “lang-en”: “Weight”}
DBW1000	Ja	300-1.000 Nm	1″	1370 mm	8,8 Kg

*Tilt screen for optimal image

Product overview

{“lang-nl”: “Model”, “lang-en”: “Model”}	{“lang-nl”: “Digitaal”, “lang-en”: “Digital”}	{“lang-nl”: “Momentbereik”, “lang-en”: “Range”}	{“lang-nl”: “Ratelkop”, “lang-en”: “Ratchet”}	{“lang-nl”: “Lengte”, “lang-en”: “Length”}	{“lang-nl”: “Gewicht”, “lang-en”: “Weight”}
DBW1000	Ja	300-1.000 Nm	1″	1370 mm	8,8 Kg

Features	Mechanical	Digital	Preset
Track	No	Yes	Yes
Peak	No	Yes	Yes
Presets	No	99	99
PC Software	No	Yes	Yes

*Tilt screen for optimal image

Features

Features	Mechanical	Digital	Preset
Track	No	Yes	Yes
Peak	No	Yes	Yes
Presets	No	99	99
PC Software	No	Yes	Yes
